Revotech IP Camera 3MP POE 2.8-12mm Manual Zoom Indoor Mini H.265 HD Security ONVIF P2P CCTV Cam Video Surveillance System

Brand Name : REVODATA
Model Number : I712-FHW
Color : black
Origin : Mainland China
Installation : Ceiling
Certification : CE
Special Features : Mini
Operating Temperature : -10-60
Sensor : CMOS
Style : Mini Camera
Shell Material : Metal
is_customized : Yes
High Definition : 3.0 Megapixels
Megapixels : 3MP
Scene : Indoor
Connectivity : IP/Network Wired
Lens (mm) : 2.8-12mm
Minimum Illumination(Lux) : NA
IR Distance(m) : 0
Video Compression Format : H.264,H.265
Supported Mobile Systems : IOS,Android
Supported Operating Systems : Windows 10,Windows Vista,Windows 8,Windows 7,Windows 98,Windows XP
Power Supply(V) : POE48V / DC12V
Power Consumption(W) : NA
Dimensions (L x W x D)(mm) : 5.6 x 4.6 x 6.3cm
Audio Output : NA
Storage : None
Power Supply : With POE
TF Card : None
Smart home platform : none
AI Functions : Motion Detection
Hign-concerned Chemical : None
Year : 2024


Features:
- 3MP High Resolution 2304*1296P
- HD 3.0MP 2.8 - 12mm Zoom Lens

- Support Motion Detection, Email Alarm function
- Support H.265 encode, compare with H.264, transit same quality image only need half of the bandwidth; Record same quality image only need half of the storage;
- It also supports H.264 encode, so it can be compatible with both H.264 and H.265 devices.
- Support POE, reduce the trouble of cable arrangement- Have auxiliary power supply, can be used like a Non
- Support iPhone, and Android smartphone
- P2P Cloud Function
- Support Multi-Language
- Day & Night Vision
- Metal Material Shell
- Net Weight: 0.3KG
- Simple Operation and Easy to Use
- NOTE:

1. IP camera will create more heat and the case of this camera is small, so after you operate the camera for a while, you will feel the camera is hot. And do not worry, it is normal and safe, hope you can understand.

2. This camera defaults to 3MP & H.265, if your NVR does not support 3MP or H.265, you can change our camera into 1080P (2MP) and H.264.

3. The" POE 48V" Option means the camera support POE, can power from POE, and needs to connect with an a802.3Aan F Standard 48V POE Switch (It has an auxiliary power supply connector, and can be used like a Non-POE IP camera).

4. The "DC 12V" Option means the camera is a regular version, does not support POE, and can only be used with a 12V regular power.

Power supply Note:

1.

POE 48V version

can

power from POE

, need to connect with a802.3AF Standard 48V POE Switch. if you need one, please click the picture to buy.

2.Both

POE 48V version

and

DC 12V

version

have not include power adapter, if you need one, please click the picture to buy.

Camera

Model: I712-FHW

Resolution:2304 x 1296P 3.0mega Pixels camera

Sensor: FH8852+GC2053

Min illumination: 0.1Lux @(F1.2,AGC ON)

Frame rate: 25fps

Shutter: 1/25 seconds -1/100,000 seconds

Compression Format: H.264/H.265

Compression rate output: 128 Kbps~8Mbps

Storage: NVR or Computer

IP address: Dynamic (Default) / Static

Smart alarm: Motion detection, Email alarm, CMS alarm

Support protocol: HTTP, TCP/IP, ICMP.RTSP, RTP, RTCP, SMTP, DHCP, DNS, PPPoE, NTP

Input protocol: The standard ONVIF

General function: A key recovery, dual stream, password protection, video hiding

Ethernet: 10M / 100M Mbps Ethernet (RJ-45)

General

Operating Temperature: -25C~60C

Operating Humidity: 10

Power Supply:

POE 48V option support POE 48V(802.3af) & DC12V/2A

DC 12V option support DC12V/2A

POE Standard: 802.3af

Housing Material: Metal

Dimension:

5.6 x 4.6 x 6.3cm

Weight:0.23kg

Package Content

1 x Camera

1 xUser Manual

1 x Screws Set

H.265 POE HD 3MP 2.8-12mm Manual Zoom Indoor IP Camera 1296P / 1080P Mini Security ONVIF P2P CCTV Cam Video Surveillance System

Daytime + Indoor

Night with light + Indoor

Browser Views

CMS Views

How to download and use the CMS? Please click here to know it.

Support Multi-Language

App Views

How to download and use the APP? Please click here to know it.

NOTE

:

System 1 also can save the video by CMS software, but it need to set and open the computer all the time. It is not convenient, so we suggest your to use system 2 to save the video. It is stable and reliable.
