LD06 Lidar LD19 D300 DTOF 3D Scanner 12M Range 360° Black Support ROS ROS2 Raspberry Pi Jetson Robotics Mapping

Scan Breadth : A3 Type : BarPREORDERe Scanner Interface Type : USB Scan Element Type : CCD Scan Speed : 100 scans/second Optical Resolution : 300*300 Brand Name : Haohsat Origin : Mainland China LD06 Lidar LD19 D300 DTOF 3D Scanner 12M Range 360 Black Support ROS ROS2 Raspberry Pi Jetson Robotics Mapping It is mainly composed of ranging core, wireless transmission unit, wireless communication unit, angle measuring unit, motor driving unit and mechanical housing. The ranging core adopts DTOF technology to measure 4500 times each second. When it works, lidar emits the infrared forward, the is reflected to the single photon receiving unit after encountering the target object. Thus, we get both time of emitting and receiving, the space between them is time of flight. With the light speed, we can calculate the distance. After receiving distance data, lidar will combine them with angel value getting from angle measurement unit to comprise the points cloud data, then transmitting the points cloud data to external interface via wireless communication. Meanwhile the external interface provides PWM to allow motor driving unit to drive the motor. After the external control unit gets the rotational speed , it will reach to specified speed through PID algorithm closed-loop control to ensure LD06 work stably. Colour:black Material:plastic Package Contents: 1 x LD06 sensor Kit 1 x English manual Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
