[MC4 --- Ferrule] PV Cable 1500V H1Z2Z2-K 6mm2 Tinned copper L=1M

KABEL PANEL SURYA OUTDOOR H1Z2Z2-K / PV-1F Spesifikasi: - Jenis Kabel : H1Z2Z2-K - Kabel ukuran 6 mm2 - Warna kabel Merah dan Hitam (Sepasang) - Arus maksimum 70A - Panjang kabel : 1 meter Note: - Produk sebagaimana terlihat pada gambar Aplikasi: - Sambungan antara Panel Surya (MC4) ke MCB DC - Sambungan antara Panel Surya (MC4) ke SCC / Solar Controller - Sambungan antara Panel Surya (MC4) ke Inverter Features: - Stable conduction and reduced maintenance costs - Anticipate service life -25 years outdoors - RoHS and CE amp; TV(EN50618 H1Z2Z2-K) Spesifikasi: - Standard : EN50618 - Construction : H1Z2Z2-K 6mm2 - Conductor Size : 6mm2 - Conductor Material : Tinned copper wire - Insulation Material : XLPO - Voltage Rating : DC1500V - Temperature Rating : -40~90 - Dielectric Strength : AC-6.5kV/5min - Spark Test : AC-10kV/In the air - Conductor resistance : 8.65KM Max at20 - Weathering/UV-resistance : 720hNo cracking - Thermal endurance properties : 25 Years - Ozone resistance : 252*24h No cracking - Cold bend test : -402*16h No cracking - Cold impact test : -40*16h/1000g100mm No cracking - Flame test : IEC 60332
