Smar H.265 Max 4K Output CCTV NVR Face Detection 9CH 10CH /16CH 32CH 4K Security Video Recorder Motion Detect P2P Onvif XMEYE

Welcome To Our Store
Kami Adalah Sumber Tangan Pertama, Penjualan Skala Besar, Harga Eceran Sama Dengan Harga Grosir. Semua barang adalah barang impor, tanyakan persediaan sebelum membeli

Brand Name : smar
Model Number : NX1009K/N008F/N1016GL
Technology : Network
Origin : Mainland China
Certification : none
Compression Format : H.265,H.264
Audio Input : No
Audio Compression Format : G711A
Video Standard : NTSC,PAL
Video Resolution : 960P,720p,1080p,5MP,3MP,4MP
Audio Output : None
Hard drive Interface Type : SATA
Hard Drive Size : 3.5''
Network Interface : RJ45 10/100M
Communication Interface : RS232
Network Protocol : SMTP,FTP,HTTP,DHCP,DNS,TCP/IP,UPNP,DDNS,PPPoE
Wireless Security : WPA2
IP Mode : Dynamic IP address,Static IP address
Supported Mobile Systems : iPhone OS,Android,Windows Mobile
Supported Operating Systems : Microsoft Windows 2000,Microsoft Windows ME,Microsoft Windows Vista,Microsoft Windows 98,Microsoft Windows 7
Backup Type : Hard Drive,Recorder,USB Flash Divers
Alarm Action : FTP Photo,Email Photo,Local Alarm
Two-way Audio : no
e-Cloud(P2P) : YES
POE : None
Smart home platform : none
Hign-concerned Chemical : None
32CH : 32CH is NT98323,Support 32*4K IP Camera


32CH NVR is differences with9CH/ 10CH/16CH NVR
Differences1: 32CH Shell Material: Botton Metal(White), 9CH/10CH/16CH Shell Material:Plastic(Full Black)
Differeance2:Video Input(IP): 9CH Max support 9*4K IP Cameras,10CH max support 10*4K IP Cameras,16CH max support 16*4K IP Cameras,32CH max support 32*4K IP Cameras.

Same: Other function are the same,as H.265 Video Compression,motion detection,Email alarm,Multiple Language....
Please check the picture as follow

Specifications

9CH

10CH

16CH

32CH

System

Mainprocessor

XM8536D

XM8536E

XM8536E

NT98323

OperatingSystem

EmbeddedLinux

Systemresources

Simultaneousmulti-channelreal-timerecording,playback,networkoperation,USBbackup

Interface

Operatorinterface

16-bittruecolorgraphicmenuoperationinterface,supportmouseoperation

Preview

1/2/4/6/8/9

1/2/4/6/
9/10

1/2/4/6/8/9/16

1/2/4/6/8/9/16/36

Video

Videoinput(IP

9*4KUnreal-timeAccessbandwidth60Mbps

10*4KAccessbandwidth72Mbps

16*4KAccessbandwidth72Mbps

36*4K

Videocompression

H.265AI/H.265+(compatibleH.265/H.264)

Displayquality

Max:4K

Playbackquality

4K/5M/4M/3M/1080P

VR

Not support

humanshape/Face

Support(dependoncamera,the camera of NETIP protocol can support face recognition)

Audio

Audiocompression

G.711A

Intercom

support

Record & playback

Recordingmode

Manual>Alarm>DynamicDetection>Timing

Localpayback(real-time+

Unreal-time)

1ch4K/2ch5M/1ch4M
/2ch3M/3h1080P

1ch4k/2ch5M/2ch4M/
3ch3M/5ch1080P

1ch4k/2ch5M/2ch4M/
3ch3M/4ch1080P

2ch4K@12fps/3ch5M@20fps/4ch4M@20fps/4ch3M@20fps/6ch1080P@25fps

Searchmode

SearchbyTime/Calendar/Event/Channel/Face

Recordstorage

HDDNetwork

Backupmode

Networkbackup,USBharddisk,USBburner,SATAburner

External

interface

Videooutput

1chVGA1chHDMIHDoutpu
t

AudioI/O

1/13.5mm

AlarmI/O

0/0

Networkinterface

1*RJ4510M/100MAdaptiveEthernetport

1*RJ45100M/1000MAdaptiveEthernetport

USBinterface

2*USB2.0ports(oneUSBextensioninterfaceisreserved)

HDD

1SATA(Upto14TBforeachdisk)

ESATA

No

Serialinterface

No

Other

ONVIF

Support

power supplyr

DC12V2A(If the hard drive is greater than 2TB, please replace it with a 3A or higher power supply)

PowerConsumption

<10W(WithoutHDD)

Workenvironment

Temperature:0C55C,Humidity:10RH,Atm:86kpa106kp

Packing List:
1* 9CH/ 10CH/16CH/32CH H.265 NVR
1* USB Mouse
1* DC12V Power Adapter for NVR
1* User's Manual

For 9CH NVR:
1. 9CH: it's XM8536D Chip;

2. Max support 9*4K(8MP) IP Camera

3. Don't support Wifi Adapter;

4. 9CH(XM) Max Support 1920x1080P Display

5.Support Multiple Languages: Chinese, English, Italian, Spanish, Japanese, Russian, French, Germany, Portuguese, Turkish, Greek, Vietnamese, Indonesian, Czech

For 10CH NVR:
1.10CH:It's XM8536E Chip
(The inventory chips in the Moscow warehouse areMstar)

2. Max support 10*4K(8MP) IP Camera

3. Don't support Wifi Adapter;

4.10CH(Hi3536) Max Support the 4K Display

5.Support Multiple Languages: Chinese, English, Italian, Spanish, Japanese, Russian, French, Germany, Portuguese, Turkish, Greek, Vietnamese, Indonesian, Czech

For 16CH NVR:

1.16CH is XM8536E Chip;
2. Max support 16*4K(8MP) IP Camera
3. Don't Support Wifi Adapter

4.16CH(XM8536E) Board Max Support the 4K Display
5.Support Multiple Languages: Chinese, English, Italian, Spanish, Japanese, Russian, French, Germany, Portuguese, Turkish, Greek, Vietnamese, Indonesian, Czech

For 32CH NVR:
1.32CH is NT98323 Chip;

2. Max support 36*4K(8MP) IP Camera

3. Support Wifi Adapter, the Wifi Adapter model is:7601

4.32CH(NT982323) Max Support the 4K Display

5.Support Multiple Languages: Chinese, English, Italian, Spanish, Japanese, Russian, French, Germany, Portuguese, Turkish, Polish, Romanian, Hungarian, Finnish, Persian, Thai, Greek, Vietnamese, Brazilian, Hebrew, Indonesian, Arabic,
